Fully Automatic Leaf Spring Hot Stamping Production Line
  • Fully Automatic Leaf Spring Hot Stamping Production Line
  • Fully Automatic Leaf Spring Hot Stamping Production Line
  • Fully Automatic Leaf Spring Hot Stamping Production Line
  • Fully Automatic Leaf Spring Hot Stamping Production Line

Fully Automatic Leaf Spring Hot Stamping Production Line

Efficient Integrated Production: Designed for hot stamping automotive leaf springs and similar components, this line integrates medium-frequency induction heating with high-precision pressing. It supports a rapid production cycle of 6-15 seconds per piece, significantly boosting mass production efficiency.
Localized Precision Induction Heating: Utilizing advanced induction heating, the system focuses heat only on the stamping area. It features minimal heat conduction, precise temperature control (800-900℃), and high efficiency, allowing operators to safely handle non-heated sections of the workpiece.
Superior Processing Precision and Quality: Equipped with a high-rigidity press (20T-1000T), the line ensures consistent product dimensions. Multi-station designs effectively control dimensional tolerances and improve shape stability for parts.
Highly Intelligent Control: The entire line is controlled by a PLC and HMI touchscreen, supporting automatic mold changes, feeding, and unloading. The system includes data acquisition for real-time monitoring of operation status, fault alarms, and maintenance schedules.
Energy-Saving and Safety: Induction heating technology is more energy-efficient with lower consumption compared to traditional furnaces.
The equipment is fitted with photoelectric protection, emergency stop buttons, and safety covers to ensure operator safety during continuous production.


No. Equipment model Corresponding processing specifications
(Steel plate thickness)		 Production cycle
1 10KHZ-250KW 16-30mm 10-15s
2 10KHZ-350KW 16-30mm 6-10s







Contact Us
